PP2150
Optimal All-in-one Panel PC engineered for performance, durability, and flexibility.
PP2150 is 21.5-inch Panel PCs combine a sleek, durable design with reliable performance for demanding industrial and commercial applications. Featuring high-quality displays, flexible mounting options, powerful computing capabilities, and extensive I/O connectivity, they provide an efficient all-in-one solution for automation, retail, hospitality, and smart business environments.
PP2150
Optimal All-in-one Panel PC engineered for performance, durability, and flexibility.
PP2150 is 21.5-inch Panel PCs combine a sleek, durable design with reliable performance for demanding industrial and commercial applications. Featuring high-quality displays, flexible mounting options, powerful computing capabilities, and extensive I/O connectivity, they provide an efficient all-in-one solution for automation, retail, hospitality, and smart business environments.
The best choice for stability and durabilityOne Panel. Endless Possibilities.
Power Meets Precision
Certified with Google Mobile ServicesFull support for Google’s core services & application ecosystem
➤ Support the latest Android 15 version
➤ Multi-system compatibility
➤ Multi-system compatibility
Depending on your use case, MSR / Stand / 2D Scanner Multi-Component SupportChoose the right architecture based on specific operational requirements today
PP2150
Depending on
your use case,
MSR / Stand / 2D Scanner
Multi-Component
Support
MSR
(Magnetic Stripe Reader)
Stand
(Liquid Crystal Display Module)
Monitor
(21.5 inch PCAP Multitouch)
2D Scanner
(QR & Barcode Scanner)
Specification
| PP2150 |
|---|
| CPU | Intel® Tiger Lake Core™ i3-1115G4 Processor Intel® Tiger Lake Core™ i5-1135G7 Processor Intel® Alder Lake N97/N100 Intel® Alder Lake i3-N305 Quad-core Cortex-A55 RK3568 Processor MediaTek Genio700 Octa-core 2x ARM Cortex A78@2.2 GHz, 6x ARM Cortex A55@2.0 GH |
|---|---|
| Memory | 2 x DDR4 SO-DIMM slot , Max up to 64GB (Tiger Lake i3/i5) 1 x DDR5 SO-DIMM slot , Max up to 32GB – depends on diff. CPU (Alder Lake N) 4G DDR4 (RK3568) 8G LPDDR4 (Genio700) |
| Storage | 1 x M.2 2242 or 1 x 2280 PCIe , Max up to 512G (Tiger Lake i3/i5) 1 x M.2 2280 or 1x 2280 PCIe , Max up to 1T (Alder Lake N97/i3-N305) 64G eMMC (RK3568) 128G (Genio700) |
| Power | 60W (24V) Stadard for RK3568 120W (24V) Standard for Tiger Lake, Alder Lake N and G700 (※) POE 24V/25W [option] (Genio700 & RK3568) |
| Audio | 2 x 2W Speaker |
| Display | 21.5″ TFT-LCD , PCAP touch , 500 nits |
| Resolution | 1920 x 1080 |
| I/O (Tiger Lake) |
1 x 24V DC-IN (Mini DIN) 1 x Power Button 3 x COM , RI/5V/12V (RJ45) 4 x USB 3.0 (Type-A) 1 x 12V/24V Cash Drawer (RJ11) 1 x Video Port 1 x Giga LAN (RJ45) |
| I/O (Alder Lake N) |
1 x 24V DC-IN (Mini DIN) 1 x Power Button 1 x COM , RI/5V/12V (RJ45) 4 x USB 2.0 (Type-A) 2 x USB 3.0 (Type-A) 1 x USB (Type-C) 1 x 12V/24V Cash Drawer (RJ11) 1 x Video Port 1 x Giga LAN (RJ45) |
| I/O (RK3568) |
1 x 24V DC-IN (Mini DIN) 1 x Power Button 1 x COM , RI/5V/12V (RJ50) 2 x USB 3.0 (Type-A) 2 x USB 2.0 (Type-A) 1 x 12V/24V Cash Drawer (RJ11) 1 x GigaLAN (RJ45) 1 x Micro SD Slot |
| I/O (Genio700) |
1 x 24V DC-IN 1 x Power Button 1 x GigaLAN (RJ45) 1 x 12V/24V Cash Drawer (RJ11) 2 x USB 3.0 (Type-A) 2 x USB 2.0 (Type-A) 1 x COM (RJ45) 1 x USB (Type-C) 1 x Video Port 1 x Micro SD Card (Top) 1 x Nano SIM Card (Bottom) 1 x Recovery Button |
| Dimension | 540 x 335 x 50 mm (W x H x D) |
| Weight | 6.5 kgs |
| OS | Windows 10 LTSC/Windows 11 LTSC/Linux 22.04/Ubuntu Android 13 (RK3568) Android 15/Ubuntu (Genio700) |
| Certifications | CE/FCC |
| Environment | Operating : 0°C ~ 40°C , 20% ~ 80% RH Storage : -20°C ~ 60°C , 10% ~ 90% RH |
| Option I/O | SKU 1 : 1 x Power USB 12V + 2x USB 2.0 SKU2 : 1 x Power USB 24V + 2x USB 2.0 WiFi802.11zc, ax/Bluetooth, 5.3LTE 4GPOE ModuleSoftPOS |
※ Limited Power Delivery for Alder Lake-N, refer to the service manual for details.
