PL5100
Fast, accurate barcode scanning with a compact, durable design for POS environments.
PL5100 is a high-performance barcode scanner designed for fast and accurate scanning. Its compact, durable design delivers reliable operation in retail, restaurants, supermarkets, and various POS environments, providing smooth and efficient checkout experiences.
PL5100
Fast, accurate barcode scanning with a compact, durable design for POS environments.
PL5100 is a high-performance barcode scanner designed for fast and accurate scanning. Its compact, durable design delivers reliable operation in retail, restaurants, supermarkets, and various POS environments, providing smooth and efficient checkout experiences.
Specification
| PL5100 |
|---|
| Light Source | Red LED (Lighting) Color Temperature 650nm LED |
|---|---|
| CPU | 32-bit Processor |
| Scan Mode | Automatic sensing and continuous scanning |
| Image Size | 640×480 Pixels |
| Scanning Speed | 120 fps/s |
| Mobile Tolerance | 1.5m/s |
| Mnimum Resolution | ≥4mil |
| Scanning Direction | Omnidirectional |
| Scanning Angle | Deflection 360° Inclination ±65° Rotation ±60° |
| Decoding Depth | 5~150mm (13mil code39) |
| Decoding Capability | 1D : Codabar, Code39, Code32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code93, Code128, GS1-128, UPC-A, UPC-E, EAN 8, EAN 13, GS1 DataBar(RSS14), GS1 DataBar Limited, GS1 DataBar Expanded, etc 2D : PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code, Maxicode, Hanxin code |
| Size | 88 × 53 × 153 mm (L x W x H) |
| Weight | 296.2g (Including cable) |
| Case Material | ABS+PC |
| Input Voltage | DC 5V |
| Working Current | <175mA |
| Stand-by Current | <145mA |
| Indicator | Tone and Volume adjustable |
| Interface | USB-HID, RS-232, USB-VCP |
| Cable | Straight 2m |
| Temperature (Operating) | -10°C~50°C |
| Humidity | 5% to 95% (non-condensing) |
| Temperature (Storage) | -20°C~60°C |
| Light Levels | 0~5000 Lux (fluorescence), 0~100,000 Lux (sunlight) |
