SF1560
Smart All-in-one POS system design for speed, reliability, and style.

The SF1560 is a powerful 15.6-inch desktop POS terminal designed for modern retail and hospitality environments. Powered by the latest Intel® or Android platforms, it delivers reliable performance, flexible connectivity, and versatile peripheral support. Its sleek design, durable construction, and easy integration make daily business operations more efficient.

SF1560
Smart All-in-one POS system design for speed, reliability, and style.

MSR

QR Code Scanner

2nd Monitor

Customer Display

VESA Mounting

Catalog Download

Datasheet Download

Adjust to any comfortable angleSimple & Freedom rotation

Wide-angle Flip

Certified with Google Mobile ServicesFull support for Google’s core services & application ecosystem

➤ Support the latest Android 15 version
➤ Multi-system compatibility

Depending on your use case, MSR / LCM / 2^nd Display Multi-Component SupportChoose the right architecture based on specific operational requirements today

MSR

SF1560

LCM

2D Scanner

2nd Display

Depending on
your use case,
MSR / LCM / 2^nd Display
Multi-Component
Support

MSR

(Magnetic Stripe Reader)

LCM

(Liquid Crystal Display Module)

2D Scanner

(QR & Barcode Scanner)

2nd Display

(Dual Screen POS)

Specification

SF1560

CPU	Intel® Alder Lake N97/N100 Intel® Alder Lake i3-N305 MediaTek Genio700 Octa-core 2x ARM Cortex A78@2.2 GHz, 6x ARM Cortex A55@2.0 GH
Memory	8GB DDR5 up to 32GB – depends on diff. CPU [1x Slot] (Alder Lake N) 8G (Genio700)
Storage	128G up to 1TB 1 x M.2 2280 Key M Slot [Gen 3×4/SATA Support NVMe] (Alder Lake N) 128G (Genio700)
Power	60W (24V) Limited Power Delivery (※) , 120W [Option] (Alder Lake N) 60W (24V) , POE 24V/25W [Option] (Genio700)
Audio	2 x 2W Speaker
Resolution	1920 x 1080 (FHD)
TPM 2.0	fTPM (Alder Lake N) N/A (Genio700)
I/O (Alder Lake N)	1 x DC 24V Input 1 x Power Button 1 x Giga LAN (RJ45) 1 x Cash Drawer (RJ11) 2 x USB 3.0 4 x USB 2.0 1 x COM (RJ45) 1 x USB (Type-C) 1 x Video Port 1 x M.2 SSD Slot
I/O (Genio700)	1 x DC 24V Input 1 x Power Button 1 x Giga LAN (RJ45) 1 x Cash Drawer (RJ11) 2 x USB 3.0 2 x USB 2.0 1 x COM (RJ45) 1 x USB (Type-C) 1 x Video Port 1 x Micro SD Card (Top) 1 x Nano SIM Card (Bottom) 1 x Recovery Button
Dimension	Countertop Mode : 360 x 190 x 245 mm (W x H x D) Flat Mode : 360 x 90 x 245 mm (W x H x D)
Weight	4.12 kgs
OS	Windows 10 LTSC/Windows 11 LTSC/Linux 22.04/Ubuntu (Alder Lake N) Android 15/Ubuntu (Genio700)
Certifications	CE/FCC/UKCA/LVD
Environment	Operating : 0˚C ~ 40˚C (32˚F ~ 104˚F) Storage : -20˚C ~ 60˚C (-4˚F ~ 140˚F)

Option

Internal I/O	WiFi802.11ac, ax/Bluetooth 5.3 (Alder Lake N) WiFi802.11ac, ax/Bluetooth 5.3 LTE/4G, POE Module, SoftPOS (Genio700)
Rear I/O	1 x line out + 1 x PUSB 24V + 2 x USB 2.0
Peripheral	MSR/NFC/2nd Display

※ Refer to the service manual for details.
